Delta Electronics has launched new 2000W AC/DC power supply designed for use in both medical and industrial applications - The IMA 2000W model comes in a compact size at 12.2” x 5” x 1.6” and provides a single 48V output with 5V/4A standby output. The 2000W Power supply is starting with the 48V Version and comes with universal AC input from 80Vac to 275Vac and wide operating temperature of -20°C to +70°C (with full power and no de-rating up to 50°C). Additional features include current sharing, analog wide voltage adjust in range of +/- 14%, and the ability to control the product’s Remote On/Off and Power Good signal. Moreover, the enclosed IMA 2000W model includes intelligent fan speed control to minimize overall system ambient noise yet maintain proper cooling.
Major approvals include IEC/EN/UL 62368-1, IEC/EN/UL 60950-1 (Industrial), and IEC/EN/UL 60601-1 (Medical). Both products are certified for EMC standards EN 55011 for industrial, scientific and medical (ISM) radio-frequency equipment, and EN 55032 for Industrial Technology Equipment (ITE) radio-frequency equipment. Full compliance with RoHS Directive 2011/65/EU for environmental protection is included.
Highlights & Features
- Safety approval for Medical (IEC 60601-1-2), Industrial (IEC 62368) and IT
- Wide operating input voltage range: 80 Vac to 275 Vac or 120 Vdc to 300 Vdc
- Wide adjustable output voltage range (+/- 14%)
- 5 Vdc standby output
- High efficiency: up to 95%
- Size: 309.6 x 127 x 40.6 mm (12.2 x 5 x 1.6 in) (1U design)
- Variable speed fan control
- Low acoustic noise level of less than 39 dB(A)
- Active current sharing
- 2 × MOPP and BF appliances
- PMBus™ compatible for control, programming and monitoring
- 500,000 hour MTBF
- Optional conformal coating
Please contact your local sales representative for product availability. Alternatively, you may leave us a message and our sales representative shall get back to you.
