Delta introduces the highly reliable low profile PMR panel mount power supply series. The PMR series is designed for LED signage application where efficient heat dissipation for the components are crucial in a low profile control cabinet. The excellent design offers highly efficient thermal management without the need for fan. This increases the reliability of the product by reducing one moving part. At only 30mm height and encased in a full corrosion resistant aluminium body, the PMR-4V320WDAA which is the first model launched in the series also has built-in active PFC circuit
Major safety approvals include IEC/EN/UL 60950-1 for Information Technology Equipment (ITE); EMI standard according to EN 55022, Class B. All Delta industrial power supplies are fully compliant with RoHS Directive 2011/65/EU for environmental protection.
Highlights & Features
- Universal AC input voltage
- Highly reliable fan-less design
- Full corrosion resistant aluminium casing
- Built-in active PFC and conforms to harmonic current IEC/EN 61000-3-2, Class A and Class D
- Low profile design for 1U installation
- High MTBF > 700,000 hrs as per Telcordia SR-332
