MOOVair 03 36V

Wireless Charging System

MOOVair 03 Seri

MOOVair 03 36V

Çıkış Voltajı

36V

Çıkış Gücü

3300W

Çıkış Akımı

88A

Giriş Voltajı Aralığı

180 - 264 Vac

Boyutlar (L x W x D)

420 x 310 x 68 mm

16.54” x 12.20” x 2.68”

Ünite Ağırlığı

20 kg (44.09 lb)

Öne Çıkanlar ve Özellikler

Easy integration into the vehicle: MOOVair 03 Wireless Charging System charges any battery type incl. Li-ion of 24 V/ 36V/ 48V. GUI (graphical user interface) available to support early integration.
No maintenance downtime. No connector wear and tear thus eliminating the need for maintenance.
Improve fleet operation & efficiency. Ethernet enables fleet managers to remotely monitor and control charging devices.
Flexible charging capability with consistent 3300W power delivery. Multiple vehicles equipped with 24V, 36V, and 48V batteries can utilize a single charging base, ensuring a consistent delivery of 3300W of power with unwavering reliability.
Exceptional efficiency - Charges just as fast and efficient as your wired charger. MOOVair 03 achieves above 92% wall socket to battery efficiency within a gap of 10 to 30mm.
The most reliable communication technology. The PPL (pad to pad link) communication technology, patented by Delta, ensures precise control of wireless power transfer. It solves WiFi crosstalk issues, enables direct communication between primary and secondary units, ensures precise wireless transfer control and eliminates interference with other WiFi devices.
Safe operation. No risk of sparks or arcing due to absence of wires and connectors.
Easy installation in the facility for unmanned 24/7 operation: MOOVair wireless charging stations are easy to install for in-process and opportunity charging without altering the facility. By demand chargers can be put in parallel to increase the power level.
Enhanced vehicle operability and control. Automated charging based on customized preconfigured parameters or vehicle-controlled via CAN bus.
Reliable performance in challenging environments: IP 65 ensuring continuous operation even in harsh and polluted environments
Safe operation. Electromagnetic field exposure as low as common household devices like induction cooktop or microwaves. Finally, all products are CE, UL (MET), FCC certified herewith meeting the highest industrial safety standards.

Uygulamalar

Wireless Charging System

MOOVair 03 Seri

MOOVair 03 36V

Öne Çıkanlar ve Özellikler

Easy integration into the vehicle: MOOVair 03 Wireless Charging System charges any battery type incl. Li-ion of 24 V/ 36V/ 48V. GUI (graphical user interface) available to support early integration.
No maintenance downtime. No connector wear and tear thus eliminating the need for maintenance.
Improve fleet operation & efficiency. Ethernet enables fleet managers to remotely monitor and control charging devices.
Flexible charging capability with consistent 3300W power delivery. Multiple vehicles equipped with 24V, 36V, and 48V batteries can utilize a single charging base, ensuring a consistent delivery of 3300W of power with unwavering reliability.
Exceptional efficiency - Charges just as fast and efficient as your wired charger. MOOVair 03 achieves above 92% wall socket to battery efficiency within a gap of 10 to 30mm.
The most reliable communication technology. The PPL (pad to pad link) communication technology, patented by Delta, ensures precise control of wireless power transfer. It solves WiFi crosstalk issues, enables direct communication between primary and secondary units, ensures precise wireless transfer control and eliminates interference with other WiFi devices.
Safe operation. No risk of sparks or arcing due to absence of wires and connectors.
Easy installation in the facility for unmanned 24/7 operation: MOOVair wireless charging stations are easy to install for in-process and opportunity charging without altering the facility. By demand chargers can be put in parallel to increase the power level.
Enhanced vehicle operability and control. Automated charging based on customized preconfigured parameters or vehicle-controlled via CAN bus.
Reliable performance in challenging environments: IP 65 ensuring continuous operation even in harsh and polluted environments
Safe operation. Electromagnetic field exposure as low as common household devices like induction cooktop or microwaves. Finally, all products are CE, UL (MET), FCC certified herewith meeting the highest industrial safety standards.

Çıkış Voltajı

36V

Çıkış Gücü

3300W

Çıkış Akımı

88A

Giriş Voltajı Aralığı

180 - 264 Vac

Boyutlar

420 x 310 x 68 mm

16.54” x 12.20” x 2.68”

Ünite Ağırlığı

20 kg (44.09 lb)

Uygulamalar

Teknik Özellikler

Output Current

88A

Output Voltage

36V

Output Voltage Range

18-49.5Vdc

Output Power

3300W

Output Current Adjustment Range

0-88A

Max Output Voltage

18-49.5Vdc

Dynamic Response (Overshoot & Undershoot O/P Voltage)

No overshoot at set point change

Remote ON/OFF

CAN control

Protective Device

Output is fused

Nominal Input Voltage

200 - 240 Vac

Input Voltage Range

180 - 264 Vac

Nominal Input Frequency

50 / 60 Hz

Input Frequency Range

47-63Hz

Input Current

16 A

Input Power (Standby Mode)

< 10 W

Efficiency at 100% load

> 92%

Inrush Current

< 65 A 10 ms

Charging Time

infinite

Power Factor at 100% load

> 0.99

Leakage Current

3.5 mA

Nominal Current

16 A

Input Voltage Phase

1-phase

Case Chassis / Cover material mix
Indicator Status LEDs: WPB
Cooling System Natural convection
Input Terminal Connector
Output Terminal Cables
Signal Terminal Connector
Noise Sound Pressure Level (SPL) -
Input/Output Terminal -
Signal -
Mounting Rail -
Wire -
Protection Structure -
Terminal -
Ünite Ağırlığı 20 kg (44.09 lb)	Boyutlar 420 x 310 x 68 mm 16.54” x 12.20” x 2.68”

Operating Temperature

WPB and WPP : -40°C to +40°C
WSB and WSP : -40°C to +70°C

Storage Temperature

-45°C to +70°C

Power De-rating

Automatic on base of internal temperature

Operating Humidity

0% to 95%, non-condensing

Operating Altitude

3,000 m (9,842 ft)

Over Voltage Category

Overvoltage

Yes

Overload / Overcurrent

Yes

Over Temperature

Yes

Short Circuit

By fuse

Reverse Polarity Protection

Yes

Degree of Protection

WPB : IP65
WPP and WSP : IP67
WSB : IP65

Protection Against Shock

Class I

Battery Polarity Protection

Yes

Internal Fuse

Yes

Insufficient Input Voltage Protection

Yes

MTBF

100khrs.(Telecordia SR-332, Method I, Case III, Issue 2, 90%confidence level, based on component stress).

Expected Cap Life Time

5 years

Safety Certificate

USA
Safety marks: cMETus

Europe
Safety marks: CE

Electrical Safety

IEC 60950-1
IEC 62368-1

Yes

Isolation Resistance

> 100,000 Ohm

PE Resistance

< 1 Ohm

Emission

CISPR 11, FCC part 18 subpart C

Immunity

EN 61000-6-2

Nominal Battery Voltage

36 V

Battery Voltage Range

18 - 49.5 Vdc

Battery Charging Mode

Set points from vehicle: CANopen®
Set points from infrastructure: Ethernet
Pre-programmed standalone operation: User programmable CC-CV profile, Multi-stage charge profile

End of Charge Voltage

49.5 V

Battery Charging Current

88 A

Battery Current Consumption

2 W

Discharging Current

2 W
